Panel Details
Panel Features
Panel Specifications
Rib Height: 1”
Panel Length: 3’ to 48’
Net Coverage: 16”(standard) or 12- 18” available for special orders
Slope: 3:12 Minimum Roof Slope
Pan Selection: Flat and Striated
Required Fasteners: Rivets
Material Type: Standard Galvalume (Zincalume) or Galvanized available for special orders
Available Gauges: 24 Standard and 26 available for special orders
Fasteners: Concealed Fasteners
Finish: Standard Galvalume Bare or SMP available for special orders
Trim/Flashing: Standard Metroll Universal Trim/Flashing & Custom available for special orders in Bare and color
Installation: Snap-together panel system
RapidSeam is a clean and attractive standing seam roof system with easy snap together installation.
Installation Method
Preparation: Measure and prepare the roof surface, ensuring it's clean and suitable for panel installation.
Laying Panels: Start laying the panels from one end of the roof. The panels usually have a nail strip or flange which lies flat against the roof.
Fastening Panels: Secure the panels to the roof using fasteners (nails or screws) through the nail strip. The next panel is then positioned so that its seam overlaps the nail strip of the adjoining panel.
Locking Panels: The overlapping seam of the new panel is then secured, often by snapping or crimping it over the first panel’s nail strip. This creates a tight, weather-resistant seam.
Finishing: Install end caps, ridge caps, and any other necessary trim pieces. Seal any joints or edges where required.
